Digital Tube
Assembly System
helps to adjust assembly fixture in 30 minutes using real-time feedback from measurement system
replaces dozens and hundreds of traditional stationary fixtures
creates new way to digitalize assembly of welded and soldered pipelines
Flexible assembly system with innovative software on boad which helps you assemble welded/soldered pipelines
in accordance with CAD model
GET QUOTE
Fixtures adjustment process under the control of optical CMM offers improved accuracy, time efficiency, ease of use and adaptability compared to traditional assembly systems.

It revolutionizes the way pipelines are assembled by leveraging digital technologies and innovative software for precise and robust results.
HELP INDUSTRIAL
COMPANIES
to adapt manufacturing processes

based on high-accuracy measurement data.
ELIMINATE ALL
PRODUCTION DEFECTS
by development of prompt response tools
to predict defects and avoid them.
EXPLORE OUR FEATURES
High speed of tooling adjustment and fixture set up, no high qualification requirements for the operator-assembler.
SPEED
Flexibility and quick changeover: assembly fixture for the required pipeline is ready "just in time".
FLEXIBILITY
Short payback period of the system.
PAYBACK
High accuracy of assembly fixture adjustment with the help of metrological optical measurement system.
ACCURACY
Reduced labor, maintenance, storage and material costs by eliminating the need for stationary fixtures.
REDUCED COSTS
SYSTEM COMPONENTS
  • Flexible adjustable tooling set

  • Intechangeable movable robust assembly tables


DOWNLOAD BROCHURE

  • Optical measurement system and control unit for the complex

  • Integrated software for technologist and operator-assembler

  • Set of industrial furniture and tools for comfortable work at the assembly area
PRODUCT LINE
Assembly working volume
2000*1000*500 mm
ArgosFix Standart
Assembly working volume
6000×1000×500 mm
ArgosFix Max
Assembly working volume
8000×4000×1500 mm
ArgosFix Titan
GO REALLY BIG
HOW IT WORKS
Support for any CAD system:
  • Siemens NX
  • SolidWorks
  • PTC Creo
  • CATIA
Create the
assembly chart
Get the right fixture set to assemble your pipeline
Prepare
the fixtures
  • Adjustment accuracy 0.1 – 0.2 mm
  • Movement and rotation along the three axes X, Y, Z
  • 6 degrees of adjustment freedom
Set up and adjust
the fixtures
  • End fittings are designed individually for the customer's pipeline
Assemble
the tube
STEP 1
STEP 2
STEP 3
STEP 4







See ArgosFix in action
and explore how it helps to adjust assembly
fixture in 30 minutes using real-time feedback
from measurement system and replaces
dozens and hundreds of traditional stationary fixtures.
